Fix USB-C SSD Not Mounting on Windows 11 & macOS (2026)

by
On this page

Portable USB-C SSDs are essential in 2026 for photo backups, 4K editing and fast project files. When they suddenly stop mounting on Windows 11 or macOS, it looks like the drive has died and panic kicks in. In reality, most “dead” SSDs are victims of bad USB-C cables, flaky USB4 docks, or a broken file system – not catastrophic hardware failure.

This guide shows you how to fix a USB-C SSD that is not showing up or not mounting on Windows 11 and macOS, step by step, without destroying your data. Work through the checks in order and you’ll quickly see whether the problem is the cable, the port, the file system, or the SSD itself.

1. Start with the USB-C cable (most common failure)

In 2026, half of the external SSD issues are caused by cables. Many USB-C leads are charge-only, limited to USB 2.0 speeds, or simply worn out. Fast SSDs need a stable 10–20 W burst of power and a proper 10 Gbps or faster data path.

  • If the SSD LED lights but the drive does not appear in Windows or macOS, the cable is suspect.
  • If the SSD disconnects when you move the connector slightly, the cable is definitely bad.
  • If the cable came bundled with a very cheap hub, do not trust it for SSDs.

Close-up of faulty USB-C cable causing SSD mount issues.

Quick tests:

  • Swap to a different USB-C cable you know works with other SSDs or fast drives.
  • Connect the SSD directly to the laptop, avoiding USB hubs, monitors or docks.
  • Try a different USB-C port on the same machine.

If the SSD suddenly mounts after swapping cables, problem solved. Replace the suspect lead with a properly rated one. For replacements, search on Amazon UK for:

2. Bypass USB4 / Thunderbolt docks and monitors

Modern USB4 and Thunderbolt docks can be a nightmare for external SSDs. Bandwidth sharing with monitors, Ethernet and charging often breaks the connection, especially with high-draw SSDs.

Symptoms of a hub or dock problem:

  • The SSD appears and disappears randomly.
  • macOS shows “Disk Not Ejected Properly” messages.
  • Windows displays “USB device not recognized” or “device malfunctioned”.

Fix:

  • Unplug the SSD from the dock and plug it directly into the laptop’s USB-C port.
  • If the SSD mounts instantly, your dock is the bottleneck.
  • Where possible, reserve one high-speed port on the dock just for storage and use a good cable.

If you need a reliable dock for SSDs, look for USB-C or Thunderbolt models specifically rated for 10 Gbps storage on Amazon UK:

3. On Windows 11 – check Disk Management first

On Windows 11, the SSD may be detected by the system but fail to receive a drive letter. That makes it invisible in File Explorer but still recoverable.

  1. Right-click the Start button and select Disk Management.
  2. Look for an entry that matches the size of your SSD.
  3. Check the status under the partition bar:
    • Healthy (Primary Partition) but no letter – problem is the missing drive letter.
    • RAW – file system is damaged.
    • Unallocated – partition table has been wiped.

Windows 11 Disk Management showing RAW unmounted SSD.

Assign a drive letter

If the volume looks healthy but has no letter:

  • Right-click the volume → Change Drive Letter and Paths.
  • Click Add and choose a free letter.

The SSD should immediately appear in File Explorer.

Dealing with RAW or unallocated space

If the file system shows as RAW or the space is Unallocated, the partition is damaged. Do not format right away if you need the data. Instead:

  • Run chkdsk X: /f (replace X with the drive letter if there is one).
  • Use dedicated recovery software if the data is critical.

Only when you are sure you do not need the data should you delete any broken partitions and create a new volume (see the formatting section later).

4. On macOS – use Disk Utility and First Aid

On macOS, the SSD often appears but refuses to mount. The easiest way to see what’s going on is Disk Utility:

  1. Open Disk Utility from Applications → Utilities.
  2. Click View → Show All Devices.
  3. Select the external SSD in the sidebar – check both the physical drive and the APFS/exFAT volume.

macOS Disk Utility showing unmounted APFS SSD.

If a volume is greyed out, click Mount. If it fails, run First Aid on the volume, then on the parent disk. First Aid often repairs minor APFS issues that block mounting.

If you still can’t mount the drive, test it on another Mac or on a Windows PC. Windows won’t read APFS, but if it detects the hardware at all, you know the SSD is at least powering up.

5. Check file system compatibility (APFS, NTFS, exFAT)

Another common problem is using the wrong file system for your workflow:

  • APFS – ideal for macOS only, invisible to Windows without third-party tools.
  • NTFS – native to Windows, macOS sees it as read-only and can misbehave if the volume is dirty.
  • exFAT – the best cross-platform choice for SSDs shared between Windows and macOS.

If you regularly move projects between Mac and PC, and your SSD is currently NTFS or APFS, consider backing it up and reformatting as exFAT. It reduces compatibility headaches and is perfectly fine for 4K/8K media.

6. Reinstall USB controllers on Windows 11

If the SSD doesn’t appear anywhere (not even in Disk Management) but other USB devices work, you may be dealing with a corrupted USB controller driver.

  1. Right-click Start → Device Manager.
  2. Expand Universal Serial Bus controllers.
  3. Right-click each USB controller and hub → Uninstall device.
  4. Restart your PC – Windows will reinstall all USB controllers automatically.

After the reboot, plug the SSD directly into the laptop again and check whether it appears.

7. Reset power management on macOS (SMC-style reset)

On older Intel Macs, odd USB behaviour is often fixed by resetting the SMC. On Apple Silicon Macs, a full shutdown performs a similar reset.

  • Intel Mac: shut down, then hold Shift + Control + Option on the left side for 10 seconds, release and power on.
  • Apple Silicon: shut down the Mac, wait 10 seconds, then power on.

After the reset, plug in the SSD with a known-good cable and test again.

8. Check SSD health and decide when to reformat

Even if the SSD is visible, it may be approaching the end of its life. Most brands offer free utilities to read SMART data and wear levels. Search on Amazon UK or the vendor’s site for your model, for example:

If SMART reports heavy wear, reallocated sectors or frequent errors, back up immediately and replace the drive. A failing SSD may work intermittently before dying for good.

When it’s safe to format

If you have a full backup or the data is not important, you can fix most mounting issues by reformatting:

  • Windows: use Disk Management → delete existing partitions → create new simple volume → format as exFAT.
  • macOS: use Disk Utility → Erase → exFAT with GUID Partition Map.

Afterwards, test the SSD on both systems to confirm it mounts instantly and transfers files at expected speeds.

9. Upgrade your workflow after fixing the drive

Once your SSD is working again, it’s a good moment to upgrade your overall storage setup so the problem doesn’t return. That means high-quality cables, a reliable SSD model, and a better backup strategy.

For more long-term buying advice, check out your dedicated guide: Best External SSDs for Travel & Photography (2025). It covers real-world performance, durability and which models survive constant travel.

10. Final checklist

  • Tested with at least two different USB-C cables.
  • Connected directly to a laptop USB-C port, not via a hub or monitor.
  • Verified presence in Windows Disk Management or macOS Disk Utility.
  • Repaired file system issues with First Aid or chkdsk where needed.
  • Reinstalled USB controllers or reset Mac power management.
  • Reformatted to exFAT only after backups were secured.

If you’ve completed that list and the SSD still never appears on any machine, the controller is likely dead and replacement is the only realistic option. In that case, invest in a reliable, well-reviewed USB-C SSD and a couple of certified high-speed cables – they cost less than a day of lost work.
